旋轉篩

     典型的旋轉篩裝料時，是將木屑和木片直接倒在篩選和進料端的層面上，落料層面的快速旋轉運動使成堆的木片鋪展開，成一定角度傾斜安裝的篩選機使物料沿篩層向下滑動落到木屑篩選層。當碎木屑在篩選過程中遇到合適的篩孔就會通過，而不能通過的大木塊和大木片繼續沿篩層向前運行。只要篩板沒有破，篩選出來的木屑尺寸應該相當均勻，并且和篩孔

的尺寸相吻合。旋轉篩之所以可行，是因為本質上這是一個碎物接近篩孔的問題，是碎物遇到尺寸合適的篩孔的概率，仔細觀察過該過程的科學家們撰寫的論文中提到——是否有可能算出任一碎物遇到并通過一個合適開度的篩孔的概率，上述理論被用來計算木材處理工業中旋轉篩選型及應用的“傳統智慧”因數，結果發現二者出奇的一致。碎物在篩板上不能找到篩孔的影響因素通常有幾個，首先是來自其他尺寸相近及較大物料的競爭。這可能是一個簡單的裝料率的問題——只要能夠為競爭碎物提供足夠的機會接近篩板，那么篩選機就會有足夠的篩選能力。

     在篩板上形成一種特定流態非常重要，在該流態下流動性好，呈湍流狀態，大量的大尺寸物料并不會妨礙木針抵達篩板表面。為了達到這種流態化，篩選機需要一定的轉速和頻率，傳統篩的典型轉速為 180 r/min，在該速度下，物料

可能以塞流狀運行而不會形成理想的流態。目前的篩選機操作速度為235～300 r/min，這種高頻率及運動振幅的調整創造了所需的流態條件。篩體的操作速度和振幅有一定的關系，轉速慢的篩體通常轉動半徑較大，高速篩轉動的振幅非常小，

這對平衡塊驅動系統驅動的篩選及控制其離心力是很有必要的。篩體旋轉速度快、振幅小，篩選效果好；而篩體旋轉速度較慢，但是要有足夠的振幅，粗篩效果還是可以的。多數鋸木廠中，一臺篩選機同時擁有精篩和粗篩這兩個功能。篩板的傾斜角度幾乎都是 7°～8°，有些木材產品篩選所用的篩引用了石料、礦物篩選所用篩。采礦所用的篩呈 20°～25°角，當篩板角度為 20°～25°時，木片在篩板表面的停留時間非常短，從而影響篩選效率。木材產品的篩選中，老式篩通常有一個笨重的鑄造底座或者組合底座來抵銷篩筐轉動過程中產生的。
====================================================================================================================================================================================
新鄉耐爾特機械設備有限公司
聯系人：孫玲
聯系方式：13072620583
地址：新鄉市牧業區宏力大道西冀場工業園
+++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++

Sawdust is usually produced in chipping process of wood powder mixed with wood chips orsawdust in the sawmill some operation process, is the need to remove the components in prior to pulping. The traditional method is to configure different sieve mesh layer vibration sieve(rotary screen) in the treatment of rotary screen, some limitations led to the development of other technologies, including now used for roll screen. These new technologies include a lot of technological innovation, the application range is more extensive, wood chip removal and some other screening method.

Rotary screen

Rotary screen loading typical, sawdust and wood chips will be poured directly on the screen andthe feed end level, falling fast rotating movement of material level make piles of wood spreadinto a certain angle, screening machine installation of the material along the screen layer sliding down to the sawdust layer of screening. When the chips met the right mesh will in the course of screening by, and not through the big wooden and large chips continue to run forward along thescreen layer. As long as the sieve plate is not broken, screening out the wood size should befairly uniform, and the sieve

Size consistent. Rotary screen is feasible, because this is essentially a debris near the meshproblem, is the probability of debris encountered suitable sieve size, carefully observe the writing of the scientists of the process mentioned in the paper -- whether it is possible to work out anydebris encountered and through a suitable opening sieve probability, the theory is used to calculate the wood processing industry rotary screening and application of "conventional wisdom" factor, the results showed that two were surprisingly consistent. Debris not on the sieve plate sieve effect factor and found there were usually several, the first is from other similar sizeand larger materials competition. This may be a simple loading rate problem -- as long as youcan provide enough opportunity to get close to the plate for competitive debris, so screening machine will have adequate screening ability.

On the sieve plate to form a specific pattern is very important in the flow of good fluidity, aturbulent state, a lot of big size material does not obstruct the wooden needle arrived in thesieve surface. In order to achieve this kind of fluidization, screening machine need speed andfrequency of some typical traditional screen, speed is 180 r/min, the speed at which, material

Flow is likely to plug flow like running without the formation of ideal. Screening machineoperating speed at present is 235 ~ 300 r/min, the high frequency and motion amplitudeadjustment to create flow conditions required. There is some relationship between the sievebody of the operation speed and amplitude, slow speed rotating sieve body usually larger radius, high speed screen rotation amplitude is very small,

This drive to balance block system driven by screening and control of the centrifugal force isvery necessary. The sieve body rotation speed, small amplitude, the screening effect is good;and the screen body rotation speed is slow, but there must be sufficient amplitude, screeningeffect can still. The majority of the sawmill, a screening machine also has fine screen and screenthese two functions. The tilt angle of the sieve plate is almost 7 degrees to 8 degrees, and somewood products used in screening sieve cited stone, mineral screening using sieve. The miningsieve is 20 DEG to 25 DEG angle, when the sieve plate at an angle of 20 DEG to 25 DEG, woodis very short residence time in the sieve surface, thus affecting the efficiency of screening.Screening of wood products, old-fashioned screen usually have a heavy casting base orcombined base to generate offset screen basket to rotate in the process of.
=++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++++
